TS

Features

• Maximum efficiency in managing regenerative loads thanks to the patented GLM function that allows regenerated energy from the loads to be reused.
• Optimised footprint for maximum installation versatility to make installation possible in any type of environment.
• Designed to minimise impact on generators and avoid overdimensioning them.
• Power factor of 1 (kW = kVA): maximum active power available at all times.
• Fail-safe: UPS signals incorrect phase sequence connection without interrupting power supply to loads from inverter and keeping batteries charged.
• Up to 4 units can be connected in parallel (up to 3.6 MW) for power or redundancy.
• Dual input and internal manual bypass
• High overload capacity of up to 300% for 3 seconds.
• High-performance battery charger for fast and efficient battery charging.
• Variable and settable battery configuration from LCD.
• Compatible with lithium-ion batteries or other technologies.
• Intelligent battery discharge test without the aid of external loads.
• Real-time battery disconnection alarm.
• Starting from battery (standard up to 20kVA, optional up to 80kVA).
• Separate or common batteries configurable for parallel systems.
• Extensive communication possibilities included: two standard ports 1xRS232 and 1xUSB, programmable dry contacts as well as two additional slots for optional boards.
• Color LCD touch screen display for intuitive interface (14 languages selectable).
• UPS information, settings and log files downloadable to removable SD card.

Main options:

• SNMP, RS485, ModBus card.
• PARALLEL KIT
• Removable internal battery compartments for easy battery maintenance.
• Internal isolation transformer (up to 40kVA).
• External temperature sensor for battery cabinet.
• Touch panel to remotely monitor up to 64 units.
• Internal backfeed contactor.
