KR PLUS XL

Features

• PF 1 ensures maximum power availability: kVA=KW for KR Plus 10-15-20-30-40 TTS.
• The patented GLM® function enables efficient management and reuse of energy produced by regenerative loads (e.g., elevators, electric motors, CNC machines, etc.).
• Compatible with lithium-ion batteries or other technologies.
• THDi <3% for low impact on the mains supply.
• The internal backfeed contactor integration eliminates the need for an external contactor.
• All models make it possible to maximize the energy available for loads with frequencies other than those of the power grid without loss of performance.
• Cold start function included.
• Designed to minimise impact on generators and avoid the need for overdimensioning them.
• Up to 95% efficiency in online mode.
• Internal manual bypass and 4-pole switches.
• Vertical internal layout ensures easy maintenance.
• Fail-safe: the UPS indicates when the phase sequence is connected incorrectly without interrupting the supply from the inverter to the loads, while keeping the batteries charged.
• High overload capacity for up to 1 minute at 150% load.
• Built-in high performance charger (10 kVA with standard charger for up to 10 A)
  Variable battery configuration: 26 to 40 individual 12V blocks settable from the touch display.
• Up to 6 units can be connected in parallel for power or redundancy, settable from the touch display
• Separate or common batteries that can be configured for parallel systems.
  4.3” colour LCD touch screen display for user-friendly interface (14 selectable languages).
• Wide range of communication options included: two ports as standard, 1xRS232 and 1xUSB, programmable dry contacts plus two additional slots for optional cards.
• Log file for up to 800 events, and UPS information and settings can be easily downloaded to an SD card.

Key options

• SNMP, RS485 ModBus and relay card with dry contacts.
• Parallel kit.
• Removable internal battery compartments for easy battery maintenance.
• External temperature sensor for a battery cabinet.
• Movable touch panel 7’’ with 3 programmable dry contacts for remotely monitoring up to 64 units.
• Internal backfeed contactor.
