MD

Features

• Thanks to the high-density design with full hot-swap technology for both power and bypass modules, continuity and protection of your load is always guaranteed.
• Power factor of 1 (kW = kVA): maximum active power available at all times.
• Very high efficiency (up to 99.3% in ECO Smart mode) for maximum energy saving: bypass and inverter work together jointly supplying power to the load and ensuring zero transfer time in case of power failure.
• Parallelable up to 4 units (up to 3.6 MW) in power or redundancy.
• Available in 60kVA solution with up to 4 strings of 40 x 9Ah internal batteries with fuses to protect each string
• Long component life for lower TCO (total cost of ownership): the Energy Saver function automatically rotates the power modules ensuring greater efficiency and durability.
• Designed to minimise impact on generators and avoid overdimensioning them.
• Ingombro ottimizzato per la massima praticità e versatilità di installazione. Installazione semplice grazie al bypass centralizzato che garantisce un migliore bilanciamento del carico e un minor rischio di sovraccarico del sistema.
• Variable and LCD-settable battery string configuration for maximum installation flexibility.
• Minimum battery voltage can be set according to the discharge current, so the batteries can always be used in the best way to maximise their expected or lifespan life.
• Minimal maintenance costs due to the use of maintenance-free capacitors.
• Cold start function included.
• Compatible with lithium-ion batteries or other technologies.
• Dual input for main power supply and bypass.
• Internal manual bypass.
• User-friendly LCD touch display with multi-language graphical user interface to have everything under control at all times.
• Event log can be downloaded directly from the LCD via USB port.
• Communication slot for optional SNMP card
• RS485-ModBus, relay card with dry contact and USB port built-in.

Principali opzioni

• SNMP card
• Isolation transformer
• Input, output and bypass line switches
• Additional battery charger for long range
